Some commands aren’t supported by the recorder and any missing steps will have to be manually edited into your macro when finished recording.Ĭontinue by performing each task you would like your macro to capture, making sure to limit any unneeded commands or keystrokes. Tech Tip: Keep in mind, the SOLIDWORKS Macro recorder will NOT capture every command while recording. Be aware that while your macro is recording, SOLIDWORKS will capture any mouse clicks, keystrokes, menu choices, as well as commands and inputs. To begin recording your new macro, go to Tools > Macro > Record. However, if you’re a beginner to macros, or even an experienced user looking for a little help with naming conventions and syntax, you can always use the Macro Record feature.
#Solidworks 2010 api how to
If you know how to program in VBA, you can add or remove code as needed here to complete your macro. Once your macro is saved, you will see the following code populate in the VBA Editor in a separate window. csproj both require Microsoft Visual Studio to edit and compile and use VB.Net and the C# programming languages, respectively.
swp which uses the Visual Basic for Applications (VBA) programming language and can be edited in the built-in SOLIDWORKS VBA Editor. Tech Tip: You have a choice between three filetypes to save your macro. Name your macro and choose where to save it. Tech Tip: You can also activate your macro toolbar by Right-Clicking on the Command Manager and selecting Toolbars > Macro. To create a new blank macro in SOLIDWORKS, go to Tools > Macro > New. This guide will walk you through how to get started creating macros and how to assign your macro to a button on your user interface for easy access. A single macro can range anywhere from performing a few simple tasks to complex programs that will change depending on user input. Macros in SOLIDWORKS are a great way to save time from having to perform repetitive tasks.
